19'' 1U MPO/MTP-LC 24F Optical Cassettes 48,72,96,144 Core MPO Fiber Optic Patch Panel
Description
This Big capacity MPO Module is an MPO pre-terminated ultra-high-density wiring box, 19-inch, 1U height up to 144 cores, and can be used in high-density wiring applications such as computer centers, computer rooms, and databases. The front and rear removable top cover, pull-out double guide, detachable front bezel, ABS lightweight module box and other technical applications make this Module easy to use in high-density scenes whether it is in the cable or cable. 144 Module has a total of E-layer trays, each with independent aluminum guide rails, and the sliding distance is 110mm. Four MPO module boxes are installed on each tray, and each module box is installed with 6 DLCs and 12 cores. Each module box has a separate ABS rail for easy sliding installation without restrictions.
Features
Design for MPO/MTP SYSTEM, for quickly network deploy and quick-fix solution
• High-density and small design
• 12 and 24 fiber versions – 144 LC (Duplex) / SC (Simplex) optical parts
• Available Multimode (62.5/125, Standard 50/125 and OM3,OM4) and Single mode(OS1/2) fiber.
• Factory-terminated and -tested cable and apparatus for instant field connections with guaranteed quality and performance
• Metallic shell with high strength protect the inner fibers effectively
• Supports easy reconfiguration for moves, adds, and changes
• Available for the installation of LC/SC adapter
Application
Data center infrastructure
Storage area network
Emerging 40 & 100Gps Protocols
Parallel optics
Enterprise network cabling systerm
Environment
Execution standard: YD/T 778 optical distribution frame
Operating temperature: -5 ° C ~ +40 ° C; storage temperature: -25 ° C ~ +55 ° C
Salt spray experiment: 72 hours
Relative humidity: ≤95% (at +40 °C)
Atmospheric pressure: 76-106kpa
Withstand voltage level: ≤3000V (DC), 1 min without breakdown, no arcing insulation resistance: ≥1000M9/500V (DC)
Insertion loss: UPC≤0.2dB; APC≤0.3dB
Return loss: UPC≥50dB; APC≥60dB
Insertion durability: ≥1000 times
Adhesion: ISO rating: Level 1;
ASTM rating: 4B.
Specification:
| | | | | Connector | Mode | Endface | IL(max) (dB) | RL(min) (dB) | IL(max) (dB) | RL(min) (dB) | | MPO/MTP | SM | 12F/APC | ≤0.70 | ≥60 | ≤0.35 | ≥60 | | 24F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 | | 48F/APC | ≤0.75 | ≥60 | | | | MM | 12F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 | | 24F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 | | 48F/PC | ≤0.50 | ≥20 | | | | LC/SC/FC/ST | SM | | ≤0.30 | ≥60 | ≤0.10 | ≥60 | | UPC | ≤0.20 | ≥50 | ≤0.10 | ≥50 | | MM | PC | ≤0.20 | ≥30 | ≤0.10 | ≥30 | |
